ATC Monitoring Relay, 3 Phase, 200/550 V ac Monitor Range, SPDT

RS stock no.:: 286-818
Mfr. Part No.:: SLU0200
Manufacturer:: ATC

ATC Monitoring Relay, 3 Phase, 200/550 V ac Monitor Range, SPDT

View all Monitoring Relays

Subtotal (1 unit)*

R 4 915,27

(exc. VAT)

R 5 652,56

(inc. VAT)

Stock information currently inaccessible - Please check back later

Units	Per unit
1 +	R 4,915.27

*price indicative

RS stock no.:: 286-818
Mfr. Part No.:: SLU0200
Manufacturer:: ATC

Specification

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ATC
	Product Type	Monitoring Relay
	Function	Monitoring
	Electrical Phase	3
	Contact Configuration	SPDT
	Power Consumption	90VA
	Switching Voltage	240V ac
	Terminal Type	8-Pin
	Monitoring Voltage Range	200/550 V ac
	Minimum Operating Temperature	32°F
	Contact Current	10A
	Maximum Operating Temperature	131°F
	Width	2.38in
	Series	SLU-0200
	Height	3in
	Standards/Approvals	UL

	Select all
	Brand ATC
	Product Type Monitoring Relay
	Function Monitoring
	Electrical Phase 3
	Contact Configuration SPDT
	Power Consumption 90VA
	Switching Voltage 240V ac
	Terminal Type 8-Pin
	Monitoring Voltage Range 200/550 V ac
	Minimum Operating Temperature 32°F
	Contact Current 10A
	Maximum Operating Temperature 131°F
	Width 2.38in
	Series SLU-0200
	Height 3in
	Standards/Approvals UL

Datasheet - SLU0200

COO (Country of Origin):: US

The ATC Phase Monitor Relays offer cost-effective protection against voltage faults in 3 phase systems (Wye or Delta). Designed for ease of use, they are adjustable for voltage, imbalance percentage, and time delay to protect against unbalanced voltages or single phasing.

Power Up 2.5 SEC Minimum

Fault Delay 1 to 25 SEC Adjustable

Severe Fault 1 SEC Phase Loss Unbalance or Phase Reversal

ATC Monitoring Relay, 3 Phase, 200/550 V ac Monitor Range, SPDT
