Hongfa Europe GMBH PCB Mount Power Relay, 12V dc Coil, 12A Switching Current, SPST
- RS stock no.:
- 176-2808
- Mfr. Part No.:
- HF115F/012-1HS3BF(610)
- Manufacturer:
- Hongfa Europe GMBH
Bulk discount available
Subtotal (1 pack of 2 units)*
R 109,55
(exc. VAT)
R 125,982
(inc. VAT)
FREE delivery for orders over R 1,500.00
Last RS stock
- 144 left, ready to ship from another location
- Final 500 unit(s) shipping from 17 December 2025
Units | Per unit | Per Pack* |
|---|---|---|
| 2 - 8 | R 54.775 | R 109.55 |
| 10 - 18 | R 53.405 | R 106.81 |
| 20 - 38 | R 51.805 | R 103.61 |
| 40 - 98 | R 49.735 | R 99.47 |
| 100 + | R 47.745 | R 95.49 |
*price indicative
- RS stock no.:
- 176-2808
- Mfr. Part No.:
- HF115F/012-1HS3BF(610)
- Manufacturer:
- Hongfa Europe GMBH
Specification
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Hongfa Europe GMBH | |
| Coil Voltage | 12V dc | |
| Contact Configuration | SPST | |
| Mounting Type | PCB Mount | |
| Switching Current | 12 A, 16A | |
| Number of Poles | 1 | |
| Latching | No | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 440V | |
| Maximum Switching Voltage DC | 300V dc | |
| Maximum Switching Current DC | 16 A | |
| Maximum Switching Current AC | 12 A, 16 A | |
| Length | 29mm | |
| Coil Resistance | 360Ω | |
| Coil Power | 400mW | |
| Isolation Coil To Contact | 10kV | |
| Minimum Operating Temperature | -40°C | |
| Series | HF115F | |
| Life | 1 x 10^7 cycles | |
| Maximum Operating Temperature | +85°C | |
| Height | 15.7mm | |
| Contact Material | Silver Alloy | |
| Depth | 12.7mm | |
| Maximum Switching Power AC | 4 kVA | |
| Select all | ||
|---|---|---|
Brand Hongfa Europe GMBH | ||
Coil Voltage 12V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 12 A, 16A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 440V | ||
Maximum Switching Voltage DC 300V dc | ||
Maximum Switching Current DC 16 A | ||
Maximum Switching Current AC 12 A, 16 A | ||
Length 29mm | ||
Coil Resistance 360Ω | ||
Coil Power 400mW | ||
Isolation Coil To Contact 10kV | ||
Minimum Operating Temperature -40°C | ||
Series HF115F | ||
Life 1 x 10^7 cycles | ||
Maximum Operating Temperature +85°C | ||
Height 15.7mm | ||
Contact Material Silver Alloy | ||
Depth 12.7mm | ||
Maximum Switching Power AC 4 kVA | ||
- COO (Country of Origin):
- CN
Low height: 15.7 mm
16A switching capability
5kV dielectric strength (between coil and contacts)
Creepage distance: 10mm
Sockets available
Plastic sealed and flux proofed types available
Environmental friendly product
Outline Dimensions: (29.0 x 12.7 x 15.7) mm
16A switching capability
5kV dielectric strength (between coil and contacts)
Creepage distance: 10mm
Sockets available
Plastic sealed and flux proofed types available
Environmental friendly product
Outline Dimensions: (29.0 x 12.7 x 15.7) mm
