Carlo Gavazzi RA 48 Series Solid State Relay, 25 A Load, Panel Mount, 530 V ac Load, 32 V dc Control

RS stock no.:: 856-8380
Mfr. Part No.:: RA4825-D12
Manufacturer:: Carlo Gavazzi

Carlo Gavazzi RA 48 Series Solid State Relay, 25 A Load, Panel Mount, 530 V ac Load, 32 V dc Control

37 Available from UK/Europe in 4–6 working days for collection or delivery to major cities (Heavy, hazardous or lithium product excluded. Delivery T&C's apply)

Not Available for premium delivery

Price (Excl VAT) Each

R 1 925,65

(exc. VAT)

R 2 214,50

(inc. VAT)

Units	Per unit
1 +	R 1 925,65

RS stock no.:: 856-8380
Mfr. Part No.:: RA4825-D12
Manufacturer:: Carlo Gavazzi

Datasheet

Attribute	Value
Maximum Load Current	25 A
Mounting Type	Panel Mount
Maximum Load Voltage	530 V ac
Minimum Load Voltage	42 V ac
Minimum Control Voltage	3 V dc
Maximum Control Voltage	32 V dc
Switching Type	Zero
Control Voltage Range	3 → 32 V dc
Minimum Load Current	150 mA
Number of Poles	1
Terminal Type	Screw
Output Device	Varistor
Relay Type	Solid State Relay
Series	RA 48
Load Voltage Range	42 → 530V ac
Maximum Turn On Time	1 s
Dimensions	44.5 x 57.8 x 24.5mm
Operating Temperature Range	-20 → +70°C
Off State Leakage Current	3 mA
Height	24.5mm
Maximum Operating Temperature	+70°C
Length	44.5mm
Minimum Operating Temperature	-20°C
Capacitance	8pF
Special Features	AC Solid State Relay, Zero Switching, Direct Copper Bonding Technology
Depth	57.8mm

Carlo Gavazzi RA 48 Series Solid State Relay, 25 A Load, Panel Mount, 530 V ac Load, 32 V dc Control

Carlo Gavazzi RA2 & RA4 Series Zero Switching
