Sensata / Crydom GN Series Solid State Relay, 25 A Load, Panel Mount, 660 V ac Load, 32V dc Control
- RS stock no.:
- 145-0539
- Distrelec Article No.:
- 137-44-851
- Mfr. Part No.:
- 84137110
- Manufacturer:
- Sensata / Crydom
Subtotal (1 unit)*
R 1 754,34
(exc. VAT)
R 2 017,49
(inc. VAT)
FREE delivery for orders over R 1,500.00
In Stock
- 4 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | R 1,754.34 |
*price indicative
- RS stock no.:
- 145-0539
- Distrelec Article No.:
- 137-44-851
- Mfr. Part No.:
- 84137110
- Manufacturer:
- Sensata / Crydom
Specification
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Sensata / Crydom | |
| Maximum Load Current | 25A | |
| Product Type | Solid State Relay | |
| Mount Type | Panel | |
| Maximum Load Voltage | 660V ac | |
| Minimum Load Voltage | 48V ac | |
| Maximum Control Voltage | 32V dc | |
| Minimum Control Voltage | 3V dc | |
| Series | GN | |
| Terminal Type | Screw | |
| IP Rating | IP20 | |
| Switching Function | Zero Cross Switching | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 80°C | |
| Height | 30.9mm | |
| Length | 44.5mm | |
| Standards/Approvals | UL, CE | |
| Capacitance | 8pF | |
| Output Type | SCR | |
| Off State Leakage Current | 0.25mArms | |
| Select all | ||
|---|---|---|
Brand Sensata / Crydom | ||
Maximum Load Current 25A | ||
Product Type Solid State Relay | ||
Mount Type Panel | ||
Maximum Load Voltage 660V ac | ||
Minimum Load Voltage 48V ac | ||
Maximum Control Voltage 32V dc | ||
Minimum Control Voltage 3V dc | ||
Series GN | ||
Terminal Type Screw | ||
IP Rating IP20 | ||
Switching Function Zero Cross Switching | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 80°C | ||
Height 30.9mm | ||
Length 44.5mm | ||
Standards/Approvals UL, CE | ||
Capacitance 8pF | ||
Output Type SCR | ||
Off State Leakage Current 0.25mArms | ||
Sensata | Crydom Solid-State Relay, Aluminium Baseplate Material, 72g Weight - GN Series - 84137110
Looking for a reliable control solution for your industrial loads? Choose this solid-state relay from Sensata | Crydom to switch your equipment on and off. As it has no moving parts, there's no risk of mechanical wear, so it's built to last. For safe handling, this piece of kit comes with a cover that has an IP20 rating, meaning it's finger-safe and protected against objects larger than 12mm in size. It has a light weight of just 72g, so it won't weigh your panel down. You can use an SSR like this one in lighting and HVAC systems.
Features & Benefits
• Integrated anti-rotation barriers for secure, vibration-proof mounting
• Built to withstand temperatures ranging between -40°C and +80°C, making it safe for use in extreme conditions
• Current rating of 25A means it's suitable for medium-duty applications
• MTBF of 1,328 years at +40°C for long-lasting performance
• Maximum turn-on and turn-off time of half a cycle for speedy switching
Is this relay fire-resistant?
Yes, this unit stops burning in 10 seconds or less, so it's a safe bet in the event of a fire.
