Huber+Suhner 85177128 RF AttenuatorStraight 5 dBMaleFemale
- RS stock no.:
- 274-2071
- Distrelec Article No.:
- 303-73-138
- Mfr. Part No.:
- 85177128
- Manufacturer:
- Huber+Suhner
Bulk discount available
Subtotal (1 unit)*
R 2 230,24
(exc. VAT)
R 2 564,78
(inc. VAT)
Add 1 unit to get free delivery
In Stock
- 1 unit(s) ready to ship from another location
- Plus 2 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 1 | R 2,230.24 |
| 2 - 2 | R 2,174.48 |
| 3 - 4 | R 2,109.25 |
| 5 - 9 | R 2,024.88 |
| 10 + | R 1,943.88 |
*price indicative
- RS stock no.:
- 274-2071
- Distrelec Article No.:
- 303-73-138
- Mfr. Part No.:
- 85177128
- Manufacturer:
- Huber+Suhner
Specification
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Huber+Suhner | |
| Product Type | RF Attenuator | |
| Interface Type | Type N | |
| Impedance | 50Ω | |
| Maximum Frequency | 6GHz | |
| Body Plating | Metal | |
| Contact Plating | Gold Plated | |
| Contact Material | Beryllium Copper Alloy | |
| Low Power | Yes | |
| Connector Type | Coaxial | |
| Minimum Operating Temperature | -55°C | |
| Maximum Attenuation | 5dB | |
| Orientation | Straight | |
| Maximum Operating Temperature | 125°C | |
| Connector Gender A | Male | |
| Series | 6805_N-50-1/1--_N | |
| Connector Gender B | Female | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand Huber+Suhner | ||
Product Type RF Attenuator | ||
Interface Type Type N | ||
Impedance 50Ω | ||
Maximum Frequency 6GHz | ||
Body Plating Metal | ||
Contact Plating Gold Plated | ||
Contact Material Beryllium Copper Alloy | ||
Low Power Yes | ||
Connector Type Coaxial | ||
Minimum Operating Temperature -55°C | ||
Maximum Attenuation 5dB | ||
Orientation Straight | ||
Maximum Operating Temperature 125°C | ||
Connector Gender A Male | ||
Series 6805_N-50-1/1--_N | ||
Connector Gender B Female | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- CN
The Huber & Suhner RF Attenuator is a low power standard type attenuator. This RF attenuator constructed with male and female type connector. It has N plug connection at one side and N jack connection at second side.
RoHS compliant
5 dB nominal attenuation
50 ohm nominal impedance
DC to 6 GHz frequency range
