Omron Voltage Monitoring Relay, 1 Phase, SPDT, 1 → 10V ac/dc

RS stock no.:: 819-3302
Mfr. Part No.:: K8AK-VW2 24VAC/DC
Manufacturer:: Omron

Omron Voltage Monitoring Relay, 1 Phase, SPDT, 1 → 10V ac/dc

Price (Excl VAT) Each

R 2 992,93

(exc. VAT)

R 3 441,87

(inc. VAT)

8 Available from UK/Europe in 4–6 working days for collection or delivery to major cities (Heavy, hazardous or lithium product excluded. Delivery T&C's apply)*

* Delivery dates may change based on your chosen quantity and delivery address.

Not Available for premium delivery

Units	Per unit
1 +	R 2 992,93

RS stock no.:: 819-3302
Mfr. Part No.:: K8AK-VW2 24VAC/DC
Manufacturer:: Omron

Omron K8AK-VS/VW Monitoring Relays

Manual resetting and automatically resetting supported by one relay
Pre-alarm monitoring mode
Compact housings
Resistant to high-frequency noise
Compliance with global power and safety standards

The Omron K8AK series monitoring relays are expertly designed for accurate and reliable monitoring of industrial facilities and equipment. The K8AK-VW/VS relays are ideal for monitoring overvoltages and undervoltages, which the K8AK-VW can do simultaneously.

K8AK-VS/VW

K8AK-TH

K8AK-VS/VW

Omron K8AK-VW Series Monitoring Relay, SPDT, DIN Rail Mounting - K8AK-VW2 24VAC/DC

This monitoring relay is designed for voltage oversight in industrial applications. It can detect both overvoltage and under voltage conditions, ensuring the performance and safety of essential electrical systems. Its DIN rail mounting feature enhances adaptability, making it a crucial component for professionals in automation and electrical engineering.

Features & Benefits

• Monitors overvoltages and under voltages to maintain system integrity
• Provides two programmable SPDT outputs for flexible control
• Includes manual and automatic reset options for convenience
• Equipped with LED indicators for clear status visualisation
• Offers pre-alarm monitoring to prevent serious failures
• Compatible with various input frequencies, increasing versatility

Applications

• Utilised for voltage regulation in industrial machinery
• Ideal for monitoring electrical systems in manufacturing facilities
• Applied in critical infrastructure for power management
• Used in automation control systems to protect operations
• Suitable for integration in electrical monitoring solutions across sectors

Is installation straightforward for the monitoring relay?

Yes, the relay is designed for easy DIN rail mounting, simplifying the installation process.

What type of input ranges can be monitored?

It can handle input ranges from 1V to 600V AC/DC, depending on the model.

How is the relay reset after an alarm activation?

The relay can be reset either manually or automatically, based on your configuration choice.

Can I monitor multiple operating conditions simultaneously?

Yes, it can simultaneously monitor both overvoltage and under voltage instances.

What is the operational temperature range for this device?

The relay operates effectively between -20°C and +60°C, making it suitable for various environments.

Standards

UL 60947-5-1, UL 508, IP 20

Attribute	Value
Monitoring Application	Voltage
Electrical Phase	1
Contact Configuration	SPDT
Voltage Sensing Range	1 → 10 V ac/dc, 15 → 150 V ac/dc, 3 → 30V ac/dc
Voltage Sensitivity	Overvoltage, Undervoltage
Time Delay	0.1 → 30s
Series	K8AK-VW
Dimensions	22.5 x 100 x 95mm
Operating Temperature Range	+60°C
Minimum Voltage Sensed	1 V ac/dc, 3 V ac/dc, 15V ac/dc
Length	22.5mm
Height	95mm
Maximum Operating Temperature	+60°C
Width	100mm
Minimum Operating Temperature	-20°C
Maximum Voltage Sensed	10 V ac/dc, 30 V ac/dc, 150V ac/dc
