Weidmuller TRS Series Interface Relay, DIN Rail Mount, 120V Coil, DPDT, 2-Pole

View this category

Subtotal (1 unit)*

R 369,02

(exc. VAT)

R 424,37

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 55 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +R 369.02

*price indicative

RS stock no.:
892-8811
Mfr. Part No.:
1123530000
Manufacturer:
Weidmüller
Find similar products by selecting one or more attributes.
Select all

Brand

Weidmüller

Coil Voltage

120V

Contact Configuration

DPDT

Mounting Type

DIN Rail

Series

TRS

Number of Poles

2

Switching Voltage

250V ac

Terminal Type

Screw

Depth

12.8mm

Height

88mm

Length

90mm

Contact Material

Silver Alloy

Input Current

(dc) 3.5 mA, (ac) 3.5mA

Input Voltage Range

120V

Turn On Time

<11ms

Minimum Operating Temperature

-40°C

Operating Temperature Range

-40 → +60°C

Turn Off Time

<7ms

Maximum Operating Temperature

+60°C

Dimensions

90 x 12.8 x 88mm

Standards Met

CE, CULus, EAC, RoHS Compliant

Special Features

Illuminated Ejection Lever, Various Protective Circuits in the Input

Relay Switching Classification

General Purpose Relay

Exempt

COO (Country of Origin):
CN

Weidmuller TERMSERIES Relay Modules


TERMSERIES complete relays modules consisting of a relay and base with AC/DC/UC coils, available in different versions:

With screw and tension-clamp connection
AgNi contact, optionally with hard gold-plated contacts
1 and 2 COs
Optionally with multiple-voltage input: 24...230 V UC
With various protective circuits in the input (free-wheel diode, RC element)
Illuminated ejection lever
