    Omron PCB Mount Signal Relay, 5V dc Coil, 1A Switching Current, DPDT

    RS stock no.:
    683-9258
    Mfr. Part No.:
    G5V-1 3DC
    Manufacturer:
    Omron
    Omron
    View all Signal Relays
    25 Available from UK/Europe in 4–6 working days for collection or delivery to major cities (Heavy, hazardous or lithium product excluded. Delivery T&C's apply)
    Add to Basket
    units

    Not Available for premium delivery

    Added

    Price (Excl VAT) Each (In a Pack of 5)

    R 48.06

    (exc. VAT)

    R 55.27

    (inc. VAT)

    unitsPer unitPer Pack*
    5 - 95R 48.06R 240.30
    100 - 120R 46.858R 234.29
    125 - 245R 45.452R 227.26
    250 - 1245R 43.634R 218.17
    1250 +R 41.888R 209.44
    *price indicative
    Packaging Options:
    RS stock no.:
    683-9258
    Mfr. Part No.:
    G5V-1 3DC
    Manufacturer:
    Omron
    COO (Country of Origin):
    CN

    Legislation and Compliance

    COO (Country of Origin):
    CN

    Product Details

    G5V-1 Series


    Fully sealed construction
    High sensitivity SPDT, 150mW nominal coil power
    Ultra-miniature, 12.5x7.5x10 mm (LxWxH)

    Approvals

    UL, CSA conforms to FCC part 68

    Specification

    AttributeValue
    Coil Voltage5V dc
    Contact ConfigurationDPDT
    Mounting TypePCB Mount
    Maximum Switching Current DC1 A
    Maximum Switching Voltage AC125V
    Maximum Switching Voltage DC60V
    SeriesIM
    Maximum Switching Power DC30 W
    Length10mm
    LatchingNo
    Depth7.5mm
    Height10mm
    Dimensions12.5 x 10 x 7.5mm
    Terminal TypeThrough Hole
    Switching Current1A
    Number of Poles2
    ApplicationSignal
    Electrical Life10^5 Operations
    Isolation Coil To Contact1.8kV rms
    Maximum Switching Power AC62.5VA
    Life5000000 (Electrical) cycles
    Coil Power150mW
    Maximum Operating Temperature+70°C
    Minimum Operating Temperature-40°C
    Contact MaterialGold Plated
    FeaturesConforms to FCC Part 68 Requirements, Single Crossbar Contacts, Fully Sealed Construction.
    Coil Resistance60Ω
    Operating Temperature Range-40 → +70°C
