Hongfa Europe GMBH PCB Mount Latching Signal Relay, 12V dc Coil, 2A Switching Current, DPDT

RS stock no.:: 176-2940
Mfr. Part No.:: HFD3/012-L2
Manufacturer:: Hongfa Europe GMBH

Hongfa Europe GMBH PCB Mount Latching Signal Relay, 12V dc Coil, 2A Switching Current, DPDT

Price Each (In a Pack of 5)**

R 46,848

(exc. VAT)

R 53,875

(inc. VAT)

40 Available from UK/Europe in 4–6 working days for collection or delivery to major cities (Heavy, hazardous or lithium product excluded. Delivery T&C's apply)*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over R 1500

Not Available for premium delivery

Units	Per unit	Per Pack**
5 - 5	R 46,848	R 234,24
10 - 20	R 45,676	R 228,38
25 +	R 44,306	R 221,53

**price indicative

RS stock no.:: 176-2940
Mfr. Part No.:: HFD3/012-L2
Manufacturer:: Hongfa Europe GMBH

Datasheet

Attribute	Value
Coil Voltage	12V dc
Contact Configuration	DPDT
Mounting Type	PCB Mount
Maximum Switching Current AC	4 A
Maximum Switching Current DC	4 A
Maximum Switching Voltage AC	277V
Maximum Switching Voltage DC	220V
Series	HFD3
Maximum Switching Power DC	90 W
Latching	Yes
Length	15mm
Depth	7.5mm
Height	9mm
Dimensions	15 x 7.5 x 9mm
Terminal Type	PCB Pin
Switching Current	2A
Number of Poles	2
Isolation Coil To Contact	2.5kV ac
Maximum Operating Temperature	+85°C
Minimum Operating Temperature	-40°C
Relay Switching Classification	Subminiature Signal Relay
Contact Material	Silver Alloy
Standards Met	CQC File No:CQC1400207409, cULus File No:E133481, VDE File No:40018867
Coil Power	200mW
Coil Resistance	720Ω
Operating Temperature Range	-40 → +85°C
Maximum Switching Power AC	62.5VA
Life	1 x 10^8 cycles
Electrical Life	1 x 10^5 cycles

Hongfa Europe GMBH PCB Mount Latching Signal Relay, 12V dc Coil, 2A Switching Current, DPDT

FREE delivery for orders over R 1500

Hongfa DPDT Latching Relay

Features and Benefits

Applications
