Omron ER Rope Pull Switch 222 mm, Left, Right, 2 NC/1 NC

RS stock no.:: 215-5012
Mfr. Part No.:: 44506-5110 ER6022-021ML
Manufacturer:: Omron

Omron ER Rope Pull Switch 222 mm, Left, Right, 2 NC/1 NC

Subtotal (1 unit)*

R 5 972,68

(exc. VAT)

R 6 868,58

(inc. VAT)

FREE delivery for orders over R 1,500.00

Temporarily out of stock

Shipping from 04 August 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	R 5,972.68

*price indicative

RS stock no.:: 215-5012
Mfr. Part No.:: 44506-5110 ER6022-021ML
Manufacturer:: Omron

Specification

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Omron
	Product Type	Rope Pull Switch
	Contact Configuration	2 NC/1 NC
	Indicator Type	LED
	Mounting Orientation	Left, Right
	IP Rating	IP67
	Number of Cable Entries	3
	Series	ER
	Reset Button	Yes
	Contact AC Voltage	240V ac
	Contact DC Voltage	24V dc
	E-Stop Button	No
	Minimum Operating Temperature	-25°C
	Maximum Operating Temperature	80°C
	Housing Material	Die Cast Aluminium
	Depth	86mm
	Length	222mm
	Standards/Approvals	CE, cUL, UL
	Width	63mm
	Hazardous Area Certification	No
	Mechanical Life	1000000Operations
	Conduit Entry	M20 x 3

	Select all
	Brand Omron
	Product Type Rope Pull Switch
	Contact Configuration 2 NC/1 NC
	Indicator Type LED
	Mounting Orientation Left, Right
	IP Rating IP67
	Number of Cable Entries 3
	Series ER
	Reset Button Yes
	Contact AC Voltage 240V ac
	Contact DC Voltage 24V dc
	E-Stop Button No
	Minimum Operating Temperature -25°C
	Maximum Operating Temperature 80°C
	Housing Material Die Cast Aluminium
	Depth 86mm
	Length 222mm
	Standards/Approvals CE, cUL, UL
	Width 63mm
	Hazardous Area Certification No
	Mechanical Life 1000000Operations
	Conduit Entry M20 x 3

Omron Series ER Rope Pull Switch, M20 x 3 Conduit Entry, IP67 - 44506-5110 ER6022-021ML

This rope pull switch provides an emergency stop function for industrial machinery and conveyor systems, enabling Rapid shutdown via a manually operated rope. It is built for harsh environments and continuous duty, offering clear Visual status indication and a manual reset mechanism to restore operation after an intervention.

Features & Benefits

• IP67 die-cast aluminium housing resists dust and water ingress
• 2NC+1NO contact arrangement supports safety-circuit architectures
• Rated for 240V AC and 24V DC to suit control and power circuits
• Mechanical life of 1 million operations supports long service intervals
• Operable from -25°C to 80°C for wide ambient conditions
• Three M20x3 cable entries allow versatile wiring access

Applications

• Suitable for emergency shutdown on conveyor belts in manufacturing plants
• Ideal for perimeter safety on packaging-line equipment
• Used with gantry and overhead transfer systems for worker protection
• Can be used for safety interlocks on material-handling conveyors
• Suitable for installation where left or right orientation is required

How is the unit reinstated after activation?

A built-in reset button must be operated to return contacts to their normal state following an actuation.

What mounting orientations are permitted for installation?

It accepts left or right mounting positions to accommodate different rope routing and machinery layouts.

How does the indicator communicate status?

An integrated LED provides a visible indication of the switch’s operational condition for quick Visual checks.

How many cable entries are provided for field wiring?

There are three dedicated cable-entry points to simplify multiple-conductor terminations.
