Multi-turn magnetic encoder: high-res

The Broadcom Angular magnetic rotary sensor that provides accurate angular measurement over a full 360 degrees of rotation. It is a versatile solution capable of supporting a broad range of applications with its robust architecture to measure and deliver both absolute and incremental signals. This sophisticated system uses integrated Hall sensor elements with complex analogue and digital signal processing within a single device. A dual track magnet generates the necessary magnetic fields by rotating perpendicularly.

PWM output modes
Programmable hysteresis
Optional 56 bit memory lock function
Compact DFN-30 leads package
INL angle correction for high accuracy
Battery backup multi turn counter
RoHS compliant
