    Advance Tapes AT525 Non-Conductive Metallic Tape, 10mm x 33m

    RS stock no.:
    542-5460
    Manufacturer:
    Advance Tapes
    Advance Tapes
    View all Metallic Tapes
    59 Available from UK/Europe in 4–6 working days for collection or delivery to major cities (Heavy, hazardous or lithium product excluded. Delivery T&C's apply)
    Add to Basket
    units

    Not Available for premium delivery

    Added

    Price (Excl VAT) Each

    R 510.07

    (exc. VAT)

    R 586.58

    (inc. VAT)

    unitsPer unit
    1 - 9R 510.07
    10 - 24R 497.32
    25 - 49R 482.40
    50 - 99R 463.10
    100 +R 444.58
    RS stock no.:
    542-5460
    Manufacturer:
    Advance Tapes

    Legislation and Compliance


    Product Details

    Advance Tapes Copper Tapes


    The Advance Tapes copper tape is a 35μ, coated with a non-conductive acrylic adhesive, supplied on a removable silicon liner. This tape is 0.07mm thick, 10mm wide and 33m long.
    Note:
    To prevent tarnishing, do not touch this tape with bare hands.

    EMI/RFI shielding tapes:
    When using this tape, galvanic compatibility should be taken into account.

    Features and Benefits


    Adhesion strength is 4.5N/cm
    Good high and low temperature resistance
    Can be easily soldered
    Easy unwind
    Breaking load is 40N/cm
    Provides superior shielding effectiveness
    Operating temperature ranges between -20°C and 155°C

    Applications


    Heating and ventilation
    Construction industry
    Manufacturing
    Duct sealing


    Specification

    AttributeValue
    Tape TypeCopper Tape
    Total Thickness0.07mm
    Foil Thickness0.035mm
    Width10mm
    Length33m
    ConductivityNon-Conductive
    Adhesion Strength4.5 N/cm
    Adhesive MaterialThermosetting Acrylic
    Material PlatingNone
    Tensile Strength40N/cm
    Maximum Temperature Resistance+155°C
    Complies with EN LegislationBS EN 60454 - Part 2
    Minimum Temperature Resistance-20°C
    Model NumberAT525
