Eaton xEffect FAZ6 MCB, 1+N, 25A Curve D, 240V AC, 10 kA Breaking Capacity

RS stock no.:: 230-1028
Mfr. Part No.:: 177535 FAZ6-D25/1N
Manufacturer:: Eaton

Eaton xEffect FAZ6 MCB, 1+N, 25A Curve D, 240V AC, 10 kA Breaking Capacity

Subtotal (1 unit)**

R 766 80

(exc. VAT)

R 881 82

(inc. VAT)

3 Available from UK/Europe in 4–6 working days for collection or delivery to major cities (Heavy, hazardous or lithium product excluded. Delivery T&C's apply)*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over R 1500

Real time stock check

Not Available for premium delivery

Units	Per unit
1 +	R 766,80

**price indicative

RS stock no.:: 230-1028
Mfr. Part No.:: 177535 FAZ6-D25/1N
Manufacturer:: Eaton

Eaton FAZ6 Series MCB, 25A Current Rating, Type D Tripping Characteristics - 177535 FAZ6-D25/1N

This is a miniature circuit breaker (MCB) designed for effective electrical circuit protection. Weighing 0.215 kg and featuring a compact form factor of 36mm in width, 72.6mm in length, and 72.6mm in depth, it is suitable for mounting on DIN rail systems. This 1P+N circuit breaker operates at a current rating of 25A and is characterised by its Type D tripping characteristics, making it ideal for various power distribution applications.

Features & Benefits

• 10kA breaking capacity ensures robust short-circuit protection
• 240V MCB designed for high-voltage networks
• Toggle switch circuit breaker for easy operation and reset
• Additional equipment can be connected for enhanced functionality
• Panel builder responsible for temperature rise calculations, ensuring adaptability

Applications

• Used for protecting electrical installations in commercial buildings
• Ideal for distribution boards in industrial settings
• Suitable for equipment requiring Type D protection characteristics
• Used for integration into various switchgear assemblies

What are the implications of the 10kA breaking capacity?

The 10kA breaking capacity signifies that this device can interrupt fault currents up to 10,000 amperes without sustaining damage. This feature is crucial for preventing potential hazards during electrical faults, thus enhancing safety in installations.

How does the Type D tripping characteristic benefit specific applications?

The Type D tripping characteristic allows the circuit breaker to handle higher inrush currents, making it particularly beneficial for inductive loads like motors and transformers. This reduces the risk of nuisance tripping during normal start-up conditions.

What considerations should be made regarding the installation of this circuit breaker?

Proper installation requires adherence to the specifications outlined in the instruction leaflet. The panel builder must ensure correct temperature rise calculations and observe switchgear specifications for optimal performance.

Is there a specific conductor cross-section that must be used with this device?

The MCB accommodates multi-wired conductors with a maximum cross-section of 25mm² and a minimum of 1mm². For solid-core conductors, the maximum is also set at 25mm² with a minimum of 1mm², allowing for a range of wiring configurations.

How is this product compliant with safety regulations?

The device meets established product standards, ensuring that it abides by safety regulations pertinent to electrical installations. Following the guidance provided in the relevant instruction literature guarantees adherence to these standards.

Note

Eaton formerly known as Moeller

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Eaton
	Number of Poles	1+N
	Current Rating	25A
	Tripping Characteristics	Type D
	Rated AC Voltage	240V
	Breaking Capacity at Maximum Voltage Rating	10 kA
	Range	xEffect
	Series	FAZ6
	Circuit Breaker Type	MCB
	Width	36mm
	Length	72.6mm
	Mounting Style	DIN Rail Mount
	Depth	72.6mm
	Model Number	FAZ6-D25/1N
	Reset Actuator Type	Toggle Switch
