Alpha Wire Ecogen Ecowire Series Dark Blue 1.5 mm² Hook Up Wire, 16 AWG, 26, 1000 ft, Modified Polyphenylene Ether, 6716
- RS stock no.:
- 282-4641
- Mfr. Part No.:
- 6716 DB001
- Manufacturer:
- Alpha Wire
Subtotal (1 reel of 305 metres)*
R 8 146,25
(exc. VAT)
R 9 368,19
(inc. VAT)
FREE delivery for orders over R 1,500.00
In Stock
- Plus 7 unit(s) shipping from 09 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | R 8,146.25 | R 26.709 |
*price indicative
- RS stock no.:
- 282-4641
- Mfr. Part No.:
- 6716 DB001
- Manufacturer:
- Alpha Wire
Specification
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Cross Sectional Area | 1.5 mm² | |
| Product Type | Hook Up Wire | |
| Jacket Colour | Dark Blue | |
| American Wire Gauge | 16AWG | |
| Core Strands | 26 | |
| Cable Length | 1000ft | |
| Outside Diameter | 0.049 in | |
| Voltage | 600 V | |
| Maximum Operating Temperature | 105°C | |
| Conductor Material | Tinned Copper | |
| Minimum Operating Temperature | -40°C | |
| Sub Type | Hookup Wire | |
| Standards/Approvals | RoHS | |
| Cable Type | Single Core | |
| Jacket Material | Modified Polyphenylene Ether | |
| Fire Behaviour | Flame Retardant | |
| Series | Ecogen Ecowire | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 1.5 mm² | ||
Product Type Hook Up Wire | ||
Jacket Colour Dark Blue | ||
American Wire Gauge 16AWG | ||
Core Strands 26 | ||
Cable Length 1000ft | ||
Outside Diameter 0.049 in | ||
Voltage 600 V | ||
Maximum Operating Temperature 105°C | ||
Conductor Material Tinned Copper | ||
Minimum Operating Temperature -40°C | ||
Sub Type Hookup Wire | ||
Standards/Approvals RoHS | ||
Cable Type Single Core | ||
Jacket Material Modified Polyphenylene Ether | ||
Fire Behaviour Flame Retardant | ||
Series Ecogen Ecowire | ||
Exempt
- COO (Country of Origin):
- MX
The Alpha Wire durable and versatile Hook up wire designed to meet the demands of various applications where reliable conductivity and corrosion resistance are crucial. The wire features a 16-gauge size and a specific construction with 26 strands, each comprising 30 individual wires.
Non-halogenated and mPPE-based insulation
Better dielectric strength
Up to 40% lighter
Fully Recyclable
Low specific gravity
