MK Electric 32A 6 Gang Switched Fused Spur BS 7288:1990, IEC 60884-1:2006, BS EN 60669-2-1, BS 4573:1970, BS EN
- RS stock no.:
- 169-1907
- Mfr. Part No.:
- K5106BSS
- Manufacturer:
- MK Electric
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS stock no.:
- 169-1907
- Mfr. Part No.:
- K5106BSS
- Manufacturer:
- MK Electric
Specification
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MK Electric | |
| Switched | Yes | |
| Product Type | Fused Spur | |
| Number of Gangs | 6 | |
| Current Rating | 32A | |
| Material | Stainless Steel | |
| Standards/Approvals | BS 7288:1990, IEC 60884-1:2006, BS EN 60669-2-1, BS 4573:1970, BS EN 60670-22:2006, BS 4177:1992, BS EN 60669-1:1999, NF C61-314, BS 1363 Pt 2:1995, BS 5733:2010, BS EN 61558-2-5:1998, BS 60669-2-4:2005, BS 546:1950, SASO 2204:2003 | |
| Mount Type | Flush | |
| Finish | Gloss | |
| Colour | White | |
| Screwed/Screwless | Screwless | |
| Number of Poles | 2 | |
| Depth | 20mm | |
| Height | 86mm | |
| Range | Albany Plus | |
| Voltage | 200, 250V | |
| Series | K5106 | |
| Width | 86mm | |
| Fixing Standard | 120.6 mm (2 GANG), 60.3 mm (1 GANG), BS, 180.9 mm (3 GANG) | |
| Minimum Box Depth | 46mm | |
| Earth Terminal | Yes | |
| Trip Current | 30mA | |
| Faceplate Depth | 15mm | |
| Select all | ||
|---|---|---|
Brand MK Electric | ||
Switched Yes | ||
Product Type Fused Spur | ||
Number of Gangs 6 | ||
Current Rating 32A | ||
Material Stainless Steel | ||
Standards/Approvals BS 7288:1990, IEC 60884-1:2006, BS EN 60669-2-1, BS 4573:1970, BS EN 60670-22:2006, BS 4177:1992, BS EN 60669-1:1999, NF C61-314, BS 1363 Pt 2:1995, BS 5733:2010, BS EN 61558-2-5:1998, BS 60669-2-4:2005, BS 546:1950, SASO 2204:2003 | ||
Mount Type Flush | ||
Finish Gloss | ||
Colour White | ||
Screwed/Screwless Screwless | ||
Number of Poles 2 | ||
Depth 20mm | ||
Height 86mm | ||
Range Albany Plus | ||
Voltage 200, 250V | ||
Series K5106 | ||
Width 86mm | ||
Fixing Standard 120.6 mm (2 GANG), 60.3 mm (1 GANG), BS, 180.9 mm (3 GANG) | ||
Minimum Box Depth 46mm | ||
Earth Terminal Yes | ||
Trip Current 30mA | ||
Faceplate Depth 15mm | ||
- COO (Country of Origin):
- GB
MK Electric White 36A Flush Mount Light Switch
The MK Electric Albany Plus white flush mount light switch is particularly designed for heavy current load commercial, domestic and industrial applications. Its unique and elegant design goes with both, conventional and unconventional interiors. This light switch ensures safety and efficiency. Its smoothly formed front plates and chamfered radius corners further add elegance to the decor.
Features and Benefits
• High durability
• Neon light indicator
• Corrosion resistant
• Tarnish resistant
• Easy installation
• Available in different textures like brushed stainless steel, brushed chrome, satin gold and polished chrome
Applications
• Household installations
• Transportation and mobility facilities
• Commercial facilities
• Industrial buildings
• Catering facilities or commercial kitchens
• Medical equipment
