Omron PCB Mount Latching Signal Relay, 24V dc Coil, 3A Switching Current, SPDT
- RS stock no.:
- 683-9472
- Mfr. Part No.:
- G6EU-134P-US 24DC
- Manufacturer:
- Omron
Bulk discount available
Subtotal (1 unit)*
R 140,56
(exc. VAT)
R 161,64
(inc. VAT)
FREE delivery for orders over R 1,500.00
In Stock
- Plus 448 unit(s) shipping from 10 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 19 | R 140.56 |
| 20 - 24 | R 137.05 |
| 25 - 49 | R 132.94 |
| 50 - 249 | R 127.62 |
| 250 + | R 122.52 |
*price indicative
- RS stock no.:
- 683-9472
- Mfr. Part No.:
- G6EU-134P-US 24DC
- Manufacturer:
- Omron
Specification
Technical data sheets
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Coil Voltage | 24V dc | |
| Contact Configuration | SPDT | |
| Mounting Type | PCB Mount | |
| Maximum Switching Current AC | 3 A | |
| Maximum Switching Current DC | 3 A | |
| Maximum Switching Voltage AC | 250V ac | |
| Maximum Switching Voltage DC | 220V dc | |
| Maximum Switching Power DC | 60 W | |
| Latching | Yes | |
| Length | 16mm | |
| Depth | 10mm | |
| Height | 8mm | |
| Dimensions | 16 x 8 x 10mm | |
| Terminal Type | Through Hole | |
| Application | Signal | |
| Switching Current | 3A | |
| Operating Temperature Range | -40 → +70°C | |
| Maximum Operating Temperature | +70°C | |
| Minimum Operating Temperature | -40°C | |
| Maximum Switching Power AC | 50VA | |
| Coil Resistance | 2880Ω | |
| Contact Material | Gold Plated | |
| Features | With PCB Stand-offs 0.30mm | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Coil Voltage 24V dc | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Maximum Switching Current AC 3 A | ||
Maximum Switching Current DC 3 A | ||
Maximum Switching Voltage AC 250V ac | ||
Maximum Switching Voltage DC 220V dc | ||
Maximum Switching Power DC 60 W | ||
Latching Yes | ||
Length 16mm | ||
Depth 10mm | ||
Height 8mm | ||
Dimensions 16 x 8 x 10mm | ||
Terminal Type Through Hole | ||
Application Signal | ||
Switching Current 3A | ||
Operating Temperature Range -40 → +70°C | ||
Maximum Operating Temperature +70°C | ||
Minimum Operating Temperature -40°C | ||
Maximum Switching Power AC 50VA | ||
Coil Resistance 2880Ω | ||
Contact Material Gold Plated | ||
Features With PCB Stand-offs 0.30mm | ||
- COO (Country of Origin):
- JP
G6E Series
SPDT subminiature signal switching relays
Fully sealed construction allows immersion cleaning of PCB
High sensitivity
Impulse withstand voltage meets FCC Part 68 requirements
Fully sealed construction allows immersion cleaning of PCB
High sensitivity
Impulse withstand voltage meets FCC Part 68 requirements
Approvals
UL, CSA
