Name: RS PRO SPDT, (On)-Off-(On) Rocker Switch Panel Mount
Brand: RS PRO
SKU: 734-6864
Price: 20.14 ZAR
Availability: Discontinued

Miniature Rocker and Paddle Switches

These Miniature Rocker and Paddle Switches are available in a variety of switch configurations with SPDT and DPDT contact configurations. Silver plated Brass contacts with a mechanical life of 40000 make and break cycles are a feature of these Miniature Rocker and Paddle Switches . All these Miniature Rocker and Paddle Switches have a UL94V0 case material with Nickel plated Brass bushings and stainless steel housings.

Stock numbers 734-6851 , 734-6855 and 734-6858 have Frames
Stock number 734-6842 has a vertical support bracket
Stock number 734-6845 has a Brass Tin plated panel support
Stock number 734-6864 has a Brass Tin plated panel support but no rocker
Stock numbers 734-6851 and 734-6842 have markings on the rocker, all other rockers have no markings
Stock number 734-6849 has a vertical rocker
Stock number 734-6839 and 734-6870 have no rocker

Rocker Switches - RS

The RS range of Miniature and Sub-Miniature Rockers Switches are available in a variety of Contact and Switch configurations.

Select all	Attribute	Value
	Brand	RS PRO
	Contact Configuration	SPDT
	Switch Operation	(On)-Off-(On)
	Contact Current Rating	5 A
	Illuminated	No
	Actuator Colour	Black
	Mounting Type	Panel Mount
	Terminal Type	Solder
	Actuator Shape	Rectangular
	DC Voltage Rating	28V
	AC Voltage Rating	125 V, 250 V
	Minimum Operating Temperature	-30°C
	Case Material	Diallyl Phthalate
	Contact Material	Silver Plated Brass
	Contact Resistance	10mΩ
	Operating Temperature Range	-30 → +85°C
	Mechanical Life	40000Operations
	Maximum Operating Temperature	+85°C

	Select all
	Brand RS PRO
	Contact Configuration SPDT
	Switch Operation (On)-Off-(On)
	Contact Current Rating 5 A
	Illuminated No
	Actuator Colour Black
	Mounting Type Panel Mount
	Terminal Type Solder
	Actuator Shape Rectangular
	DC Voltage Rating 28V
	AC Voltage Rating 125 V, 250 V
	Minimum Operating Temperature -30°C
	Case Material Diallyl Phthalate
	Contact Material Silver Plated Brass
	Contact Resistance 10mΩ
	Operating Temperature Range -30 → +85°C
	Mechanical Life 40000Operations
	Maximum Operating Temperature +85°C

RS PRO SPDT, (On)-Off-(On) Rocker Switch Panel Mount

Miniature Rocker and Paddle Switches
