Amphenol, PT 6 Way Panel Mount MIL Spec Circular Connector Receptacle, Socket Contacts,Shell Size 10, Bayonet,

RS stock no.:: 872-1452
Mfr. Part No.:: PT02E-10-6S
Manufacturer:: Amphenol Industrial

Amphenol, PT 6 Way Panel Mount MIL Spec Circular Connector Receptacle, Socket Contacts,Shell Size 10, Bayonet,

23 Available from UK/Europe in 4–6 working days for collection or delivery to major cities (Heavy, hazardous or lithium product excluded. Delivery T&C's apply)

Not Available for premium delivery

Added

View basket

Price (Excl VAT) Each

R 485,92

(exc. VAT)

R 558,81

(inc. VAT)

Units	Per unit
1 +	R 485,92

RS stock no.:: 872-1452
Mfr. Part No.:: PT02E-10-6S
Manufacturer:: Amphenol Industrial

Technical data sheets

Legislation and Compliance

Non Compliant

Product Details

Amphenol PT Series Connectors

The Amphenol PT series connectors, manufactured in accordance with MIL-DTL-26482 Series 1, is a range of high density circular connectors featuring a bayonet coupling mechanism for quick connect and disconnect. A wide range of Insert arrangements are available offering both power and signal contacts from 2 through to 61 circuits. The Amphenol PT series connectors are inter-mountable and interchangeable with other MIL-DTL-26482 connectors.

PT Solder is UL Approved Under File #E115497
Aluminum Shell Components For The Series
5 Key/ Keyway Polarisation With Bayonet Lock Coupling
Wide Range of Shell Sizes (8 Through 24)

Amphenol PT Series Connectors

Specification

Attribute	Value
Number of Contacts	6
Gender	Female
Contact Gender	Female
Voltage Rating	1 kV ac
Shell Size	10
Mounting Type	Panel Mount
Military Standard	MIL-DTL-26482
Termination Method	Solder
Mating Type	Bayonet
Connector Size	Miniature
Body Orientation	Straight
Series	PT
Housing Material	Aluminium
Shell Plating	Cadmium
Colour	Green
Contact Plating	Gold
Minimum Operating Temperature	-55°C
Contact Material	Copper Alloy
Maximum Operating Temperature	+125°C
